products
MST-BAR® is an industry leading GFRP (Glass Fiber Reinforced Polymer) Rebar built to last. It is strong, lightweight, sustainable, and doesn’t corrode. MST-BAR® is non-corrosive and non-conductive and is the perfect reinforcement solution for environments exposed to water, salt, humidity, high voltage currents, and magnetic fields. With a life span of more than 100 years, MST-BAR® is more durable & a much longer lasting solution over galvanized, epoxy coated and stainless steel. MST-BAR® is approved & manufactured in compliance with ACI 440.
MST-BAR® is an excellent replacement for conventional steel rebar.
Want to skip the technical stuff and go direct to see what MST-BAR® is capable of? Click the button below to jump to our project highlights.
1. Products overview
3MAX
3MAX is the contractor’s long-lasting and economical solution to reinforcing concrete flatwork. Provides over 2X higher tensile capacity compared to grade 60 steel rebar, strengthening concrete for generations.
sIZE
7/16-inch rib to rib diameter, 3/8-inch load-bearing core diameter.
APPLICATIONS
Applications include but are not limited to:
- Parking Lots
- Curb & Gutter
- Driveways
- Patio & Sidewalks
- Pool Decks
DATASHEET
Learn more about 3MAX by checking out the datasheet HERE. Or contact your TNL representative today.
4max
4MAX is the contractor’s long-lasting and economical solution to temperature & shrinkage crack control. Provides 80% less crack initiation compared to steel reinforcement, maintaining high-performance for centuries.
sIZE
1/2-inch rib to rib diameter, 7/16-inch load-bearing core diameter.
APPLICATIONS
Applications include but are not limited to:
- Slab on Grade
- Decorative Concrete
- Street Pavement
- Short retaining & Stem Walls
- Pool Decks
DATASHEET
Learn more about 4MAX by checking out the datasheet HERE. Or contact your TNL representative today.
4EQ Structural Bar®
4EQ Structural Bar® is a high performance rebar, engineered to replace steel rebar in vertical and structural applications. 4EQ Structural Bar® is the first GFRP rebar accepted by ICC-ES, making it compatible with the Residential Building Code and Commercial Building Code.
sIZE
1/2-inch rib to rib diameter, 7/16-inch load-bearing core diameter.
APPLICATIONS
Use 4EQ Structural Bar® with TNL’s prescriptive reinforcement guides and simplify your workflow. Applications include but are not limited to:
- Foundation Walls
- Suspended Slabs
- Most Structural Applications
DATASHEET
Learn more about 4EQ Structural Bar® by checking out the datasheet HERE. Or contact your TNL representative today.
High-Mod Bars
MST-BAR offers a full line of High-Mod Bars as a superior reinforcement system, completely replacing epoxy-coated, galvanized, stainless steel, and plain steel rebar. Stocked in sizes #3 through #8, custom lengths and diameters available upon request.
APPLICATIONS
Applications include but are not limited to:
- Commercial Construction
- Pre-cast Concrete
- Industrial & Utility
- Infrastructure & DOT + more!
DATASHEET
Learn more about High-Mod Bars by checking out the datasheet HERE. Or contact your TNL representative today.
MST-BAR® BEND
MST-BAR® can bend and produce any bent shape and any dimension quickly and efficiently. Standard pricing per linear footage regardless of bent shape makes estimating simple to complete your project.
size
Two-dimensional and three-dimensional shapes are available in sizes #3 through #6. MST-BAR® cab be bent in to any shape, 2D (along X,Y) and 3D (along X,Y,Z) and Spiral (Round or Square). The minimum bend radius is 5.5 times the diameter of the bar.
learn more
To learn more about MST-BAR® Bend Bars, contact your TNL representative today.
3MAX
3MAX is the contractor’s long-lasting and economical solution to reinforcing concrete flatwork. Provides over 2X higher tensile capacity compared to grade 60 steel rebar, strengthening concrete for generations.
sIZE
7/16-inch rib to rib diameter, 3/8-inch load-bearing core diameter.
APPLICATIONS
Applications include but are not limited to:
- Parking Lots
- Curb & Gutter
- Driveways
- Patio & Sidewalks
- Pool Decks
DATASHEET
Learn more about 3MAX by checking out the datasheet HERE. Or contact your TNL representative today.
4max
4MAX is the contractor’s long-lasting and economical solution to temperature & shrinkage crack control. Provides 80% less crack initiation compared to steel reinforcement, maintaining high-performance for centuries.
sIZE
1/2-inch rib to rib diameter, 7/16-inch load-bearing core diameter.
APPLICATIONS
Applications include but are not limited to:
- Slab on Grade
- Decorative Concrete
- Street Pavement
- Short retaining & Stem Walls
- Pool Decks
DATASHEET
Learn more about 4MAX by checking out the datasheet HERE. Or contact your TNL representative today.
4EQ Structural Bar®
4EQ Structural Bar® is a high performance rebar, engineered to replace steel rebar in vertical and structural applications. 4EQ Structural Bar® is the first GFRP rebar accepted by ICC-ES, making it compatible with the Residential Building Code and Commercial Building Code.
sIZE
1/2-inch rib to rib diameter, 7/16-inch load-bearing core diameter.
APPLICATIONS
Use 4EQ Structural Bar® with TNL’s prescriptive reinforcement guides and simplify your workflow. Applications include but are not limited to:
- Foundation Walls
- Suspended Slabs
- Most Structural Applications
DATASHEET
Learn more about 4EQ Structural Bar® by checking out the datasheet HERE. Or contact your TNL representative today.
High-Mod Bars
MST-BAR offers a full line of High-Mod Bars as a superior reinforcement system, completely replacing epoxy-coated, galvanized, stainless steel, and plain steel rebar. Stocked in sizes #3 through #8, custom lengths and diameters available upon request.
APPLICATIONS
Applications include but are not limited to:
- Commercial Construction
- Pre-cast Concrete
- Industrial & Utility
- Infrastructure & DOT + more!
DATASHEET
Learn more about High-Mod Bars by checking out the datasheet HERE. Or contact your TNL representative today.
MST-BAR® BEND
MST-BAR® can bend and produce any bent shape and any dimension quickly and efficiently. Standard pricing per linear footage regardless of bent shape makes estimating simple to complete your project.
size
Two-dimensional and three-dimensional shapes are available in sizes #3 through #6. MST-BAR® cab be bent in to any shape, 2D (along X,Y) and 3D (along X,Y,Z) and Spiral (Round or Square). The minimum bend radius is 5.5 times the diameter of the bar.
learn more
To learn more about MST-BAR® Bend Bars, contact your TNL representative today.
2. Key Advantages
- Corrosion-proof Reinforcement: Zero rust, zero spalling, eliminates costly rehabilitation and maintenance.
- 100+ Years Service Life: Engineered to extend the service life of your reinforced concrete for centuries.
- Quick & Simple Installation: Up to 50% labor savings compared to installing traditional steel rebar.
- Transportation Savings: Weighs 25% the weight of steel rebar. One truck of MST-BAR® replaces four truckloads of steel.
- High Performance in All Climates: Stronger reinforcement in freeze-thaw climates and guaranteed longevity in coastal regions.
- No Waterproofing: Eliminates need for costly waterproofing agents and epoxy coating necessitated by rust-prone steel rebar.
- MST-BAR® BEND Technology: Fastest turnaround time for factory fabricated bent bars. Our proprietary corrugated sleeve achieves any bend possible.
- Thermal Insulator: Increase your structure’s energy efficiency.
- Nonconductive & Nonferrous: Ideal for projects with electro-magnetic sensitivity.
- High Chemical Resistance: High alkaline resistance. Impervious to de-icing salts and other harsh chemical attacks.
- Environmental Sustainability: Environmentally friendly manufacturing leaves a fraction of the carbon footprint left by steel mills.
- High Fatigue Resistance: 20X higher resistance under cyclical loading compared to traditional steel rebar.
3. Resources & services
- Mesh replacement calculator.
- 4EQ foundation system calculator.
- Proprietary Finite Element Design Software available to help designers use GFRP comfortably.
- Value Engineering and Design Assistance available to support your project.
- On-site consulting available to contractors.
4. project highlights
florida seawall
MST-BAR® High-Mod Bars and MST-BAR® Bend Bars were used for this seawall project located in Florida.
INSULATED CONCRETE FORM (ICF) PROJECT
4EQ Structural Bar® and MST-BAR® Bend Bars were used for this residential home project located in Ohio.
Miscellaneous Flatwork Projects
3MAX and 4MAX were used for these various flatwork projects which include, sidewalks, patios, pool decks, driveways, and slab on grade foundations.
